Real-Time Voice AI Assistant with Function Calling & Bidirectional Audio Streaming

We built a real-time voice AI assistant powered by Google's Gemini Live API with native audio capabilities, custom function calling for domain-specific calculations, and a React frontend with WebSocket-based audio streaming.

Architecture

• AI Model: Gemini with native audio input/output and function calling
• Backend: Python/FastAPI with WebSocket endpoint for bidirectional audio
• Audio Pipeline: PyAudio for microphone/speaker I/O with real-time streaming
• Frontend: React with Vite and Tailwind CSS for session control UI
• Communication: WebSocket for low-latency JSON messaging and binary audio transport
• Multimodal: Optional camera and screen capture for visual context

Real-Time Audio Pipeline

Bidirectional Streaming

The system maintains continuous audio streams in both directions:

• Input: Microphone audio captured at 16kHz mono, chunked into small frames, and streamed to the AI model in real-time
• Output: AI-generated speech received at 24kHz and played through speakers immediately
• No Batching: Audio chunks are sent as captured — no accumulation delays
• Interrupt Handling: User can interrupt the assistant mid-response naturally

Audio Processing

• 16-bit PCM format for both input and output
• Separate sample rates optimized for speech (16kHz capture, 24kHz playback)
• Small buffer sizes for minimal latency
• Continuous streaming with no start/stop gaps between turns

Function Calling Integration

How It Works

The AI model can invoke local Python functions mid-conversation when domain-specific calculations are needed:

1. User speaks a request (e.g., "I missed lunch today")
2. AI model transcribes and understands the intent
3. Model determines a function call is needed and sends a structured request
4. Backend extracts function name, arguments, and call ID
5. Local function executes the domain calculation
6. Result sent back to the model as a structured response
7. Model generates a natural language voice response incorporating the result

Domain Functions

The system supports nutrition-focused function calling for scenarios like:

• Missed Meals — Redistributes missed macronutrients across remaining meals
• Unplanned Food — Adjusts upcoming meals to compensate for unexpected intake
• Meal Substitutions — Swaps ingredients while maintaining macro targets
• Activity Tracking — Estimates calorie burn and adjusts nutrition buffer

Each function uses a macro database with per-food nutritional profiles and performs dynamic calculations with slight stochastic variation for natural-feeling responses.

Execution Safety

• Microphone input is paused during function execution to prevent overlap
• Pending audio frames are dropped to avoid stale context
• Error responses are sent back gracefully if function execution fails
• Normal streaming resumes immediately after function completion

Backend Architecture

FastAPI WebSocket Server

• Single WebSocket endpoint for all client communication
• Session lifecycle management (start, stop, ping/pong health checks)
• One active session at a time with session locking
• CORS middleware for development environments
• Health check endpoint for monitoring

Session Management

• Sessions are created on client connect with mode selection (audio-only, camera, or screen)
• Background async tasks handle audio capture, processing, and playback concurrently
• Graceful disconnection with resource cleanup
• API key validation and error propagation

Multimodal Input (Optional)

Beyond voice, the system supports optional visual context:

• Camera Mode — Streams webcam frames (1fps) for visual context in conversations
• Screen Mode — Captures screen content for discussing on-screen information
• Images are resized and compressed before transmission
• Visual context enhances the AI's ability to provide relevant responses

Frontend Interface

• Session Control — Start/stop listening with clear status indicators
• Status Display — Real-time connection and session state (idle, connecting, active, error)
• Theme Support — Light/dark mode with persistence
• Guided Walkthrough — Step-by-step demo for first-time users
• WebSocket Management — Automatic reconnection logic

AI Model Configuration

• Native audio modality (no separate STT/TTS pipeline)
• Configurable voice selection from multiple preset voices
• System instructions defining assistant personality, response style, and language handling
• Tool definitions for all available functions with parameter schemas
• Automatic language detection with same-language response

Key Features

1. Sub-Second Latency — Native audio model eliminates STT/TTS pipeline overhead
2. Real-Time Bidirectional Audio — Continuous streaming with < 50ms per-chunk latency
3. Function Calling — Domain-specific calculations executed mid-conversation
4. Natural Interruption — Users can interrupt the assistant naturally without special commands
5. Multi-Language — Automatic language detection with same-language responses
6. Multimodal Input — Optional camera and screen context for visual understanding
7. Session Management — Session lifecycle control with locking and resource cleanup
8. Macro Calculations — Dynamic nutritional adjustments with per-food macro profiles
9. Error Recovery — Graceful handling of function failures and network interruptions
10. Extensible — New functions added by defining schema and handler — no architecture changes
